光学收发器

Mellanox MMA1L10-CR

产品描述：Mellanox MMA1L10-CR_QSFP28 100G 10KM LR4 DOM Duplex LC UPC SMF Optical Transceiver Module_liyuan Tech
在线订购

brand: Mellanox

PN: MMA1L10-CR

Form Type: QSFP28

Speed : 100GB

description: QSFP28 100G 10KM LR4 DOM Duplex LC UPC SMF Optical Transceiver Module

Optical transceiver Type: pluggable optical transceiver

Reach: 10KM

Wavelength: 1310nm.

DOM: DOM

Media: SMF

Connector: Duplex LC

Transmitter Type: 4 x LAN WDM EML

Receiver Type: PIN

TX Power: -4.3~4.5dBm

Minimum Receiver Power: -10.6dBm

Powerbudget: 6.3dB

Receiver Overload: 4.5dBm

Power Consumption: ≤3.5W

Extinction Ratio: >4dB

MMA1L10-CR has selectable retiming as specified in the QSFP28 MSA. This enables the transceiver to be used in both 40 GbE and 100 GbE applications.

Digital diagnostic monitoring functions for temperature, supply voltage, and optical power are available via the two-wire (I2C) management interface, as specified by the QSFP28 MSA.

The optical connector is a duplex LC/UPC (un-angled) connector intended for a pair of single mode fibers.

Environment: 0 to 70C .

Country of origin: Malaysia

In addition to Mellanox MMA1L10-CR , Liyuan Tech supply a wide range of other Nokia optical transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
