  • Product description: Mellanox MMA1B00-C100D MFA7A20-C003 MMA1L10-CR_QSFP28 Optical Module (MMF, 850nm, 100m, MTP/MPO, DOM)_Liyuan Tech
  • INQUIRY
Brand: Mellanox
Part Number: MMA1B00-C100D MFA7A20-C003 MMA1L10-CR
Form Factor: QSFP28
Max Data Rate: 100Gbps (4x 25Gbps)
Wavelength: 850nm
Reach: 100m
Max Cable Distance: 70m@OM3/100m@OM4
Connector: MTP/MPO-12
Media: MMF
Transmitter Type: VCSEL 850nm
Receiver Type: PIN
TX Power: -8.4~2.4dBm
Minimum Receiver Power: -10.3dBm
Powerbudget: 1.9dB
Receiver Overload: 2.4dBm
Typical Power Consumption: ≤2.5W
Extinction Ratio: >3dB
DDM/DOM: Supported
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
CDR (Clock and Data Recovery): TX & RX Built-in CDR
Inbuilt FEC: No
Protocols: IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI
Mellanox MMA1B00-C100D MFA7A20-C003 MMA1L10-CR QSFP28 Optical Module (MMF, 850nm, 100m, MTP/MPO, DOM)
The FS of the Mellanox MMA1B00-C100D MFA7A20-C003 MMA1L10-CR QSFP28 optical transceiver module is designed for 100GBASE Ethernet with a throughput of up to 100m using OM4 multimode fiber (MMF) with a wavelength of 850nm via MTP/MPO-12 connectors.
The transceiver complies with IEEE 802.3B100GBASE-SR4 and CAU-4 standards.The digital diagnostic function is also available via the I2C interface, specified by the QSFP28 MSA, allowing access to real-time operational parameters.
With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as data centers, high-performance computing networks, enterprise core and distributed layer applications.
In addition to Mellanox MMA1B00-C100D MFA7A20-C003 MMA1L10-CR , Liyuan Tech supply a wide range of other Optical transceiver transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
